Hot Runner Temperature Controller
XK cartridgeheater
Proven Quality. Trusted Results.
Tubular heaters offer efficient and reliable heat transfer, making them suitable for applications such as air heating, immersion heating, and process heating. Their compact size and flexibility in design allow them to be easily integrated into different systems and equipment.
Description
-
-
Basic Info
-
Model NO |
Xingke-010 |
Brand |
Xingke |
Display Type |
LED |
Ambient Temperature |
-10°C ~ 55°C / 14°F ~ 131°F |
Temperature Setting Range |
0c-450c/32f-842f |
Temperature Stability |
+/-0.5% |
Ambient Thumidity |
10-80% |
Transport Package |
Carton or Wooden Box |
Specification |
Control 1 zone temperature of the mold |
Production Capacity |
5000sets/Year |
Origin |
China |
HS Code |
8516800000 |
-
features
-
1、Using FUZZ + PIDD control technology, it can Automatically adjust the correct PID value, adapt to any heating model, and greatly improve work efficiency.
2、automatic environmental linear temperature compensation, making the controller temperature value more accurate.
3、error monitoring, the controller detects the temperature sensor (thermocouple) open, reverse, short Road heating elements are short-circuited, fuses are open-circuited, etc., and timely melitin alarms to remind operators.
4、heater output circuit monitoring.
5、View the output percentage
6、temperature deviation alarm
7、Leakage error monitoring
8、manual power output mode
9、soft start lock function
10、comprehensive error indication output, you can easily find the current failure cause
11、the wrong wire protection function, heating wire, temperature sensing wire will not burn the heating element
12、high temperature, high pressure alarm function
13、screen display J / K type, J type, K type are interchangeable
-
Product Parameters
-
Product Model
Xingke-1-HRC
Xingke-2-HRC
Xingke-4-HRC
Xingke-6-HRC
Xingke-8-HRC
Xingke-10-HRC
Temperature Range(ºC)
0~450
Temperature Control Accuracy(ºC)
±0.5
Supply Voltage
AC220V 50HZ 1P/PE
Total Current(A)
20
No. of groups
1
2
4
6
8
10
Output type
PWM
Types of thermocline
Thermocouple (Type J/K)
Output power(KW)
50W-1650W(110V),100W-3600W(240V)
Temperature Environment Type
FUZZY+PWM
Environmental temperature(ºC)
-10~+55
Environmental Humidity(%PH)
10-80(non-condensation)
Safety Protection Functions
Thermocouple positive and negative reversed alarm,
thermocouple short circuit alarm
Overall dimensions(CM)
27.5*28*23
33*28*23
38.5*28*23
44*28*23
44*28*46
44*28*46
Weight(KG)
2
4
8
10
16
18
Product Model
Xingke-12-HRC
Xingke-14-HRC
Xingke-16-HRC
Xingke-18-HRC
Xingke-20-HRC
Temperature Range(ºC)
0~450
Temperature Control Accuracy(ºC)
±0.5
Supply Voltage
AC220V 50HZ 1P/PE
Total Current(A)
20
No. of groups
12
14
16
18
20
Output type
PWM
Types of thermocline
Thermocouple (Type J/K)
output power(KW)
50W-1650W(110V),100W-3600W(240V)
Temperature Environment Type
FUZZY+PWM
Environmental temperature(ºC)
-10~+55
Environmental Humidity(%PH)
10-80(non-condensation)
Safety Protection Functions
Thermocouple positive and negative reversed alarm,
thermocouple short circuit alarm
Overall dimensions(CM)
44*28*46
44*28*69
44*28*69
44*28*69
44*28*92
Weight(KG)
20
26
28
30
36
-
Note: More detailed application information you provide, the better customized design and perfect fitting performance you will get.
-
FAQ
-
Q1: Can you supply customize service?
A: Yes, we can supply OEM & ODM service according to your drawings or requirement.
Q2: How long can i get the order?
A: The delivery time depends on order quantity.Normally can be ready within 7-15 working days.
Q3. How can you guarantee quality?
A: We strictly follow the agreed product parameters and material performancenn.Before delivery, we will take photos and ask you to verify the product information. If you have any other questions,please feel free to contact us.
-
